| 1 | | 9783762 | 9783762 | 9783762 | Prevailing Torque Pinion Nut | Sold as Individual Part (09783762) or Kit 74010010, 74020008, 74067005 | 1 | GMY 900, K2XX | 2007 - 2018 | | |
| 1 | | 40163645 | 11603375 | | Nut, Rear Axle Drive Pinion | Sold as Kit (925T1342GEARKIT, 925T1373GEARKIT) (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 2 | | 517900 | 517900 | 517900 | Pinion Nut Washer | Sold as Individual Part (00517900) or Kit 74010010, 74067005, 74020008 | 1 | GMY 900, K2XX | 2007 - 2018 | | |
| 2 | | 40165379 | 11603381 | | Washer, Pinion Flange | Sold as Individual Part (40165379) or Kit (925T1342GEARKIT, 925T1373GEARKIT) (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 3 | | 40025925 | 88967027 | 40025925 | Pinion Yoke (1344 UJT 4 Footed) | Sold as Individual Part (40025925) | 1 | GMY 900, K2XX | 2007 - 2015 | | |
| 3 | | 40152063 | 84000763 | 40152063 | Pinion Yoke | Sold as Individual Part | 1 | K2XX | 2016 - 2018 | | |
| 3 | | 40224929 | 85123911 | 40224929 | Flange Asm, Deflector | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| 4 | | 40007712 | 12471590 | 40007712 | Pinion Seal | Sold as Individual Part (40007712) or Kit 74010010, 74067005, 74020008 | 1 | GMY 900, K2XX | 2007 - 2018 | | |
| 4 | | 40255186 | 85656407 | | Pinion Seal | Sold as Kit (925T1342GEARKIT, 925T1373GEARKIT) (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 4 | | 40255188 | 85099033 | | Pinion Seal | Sold as Kit (925T1342GEARKIT, 925T1373GEARKIT) (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 5 | | 9417781 | 9417781 | | Small Pinion Bearing ASM (Cup & Cone) | Sold as Individual Part (09417782 roller 09417783 race) | 1 | K2XX | 2007 - 2018 | | |
| 5 | | 40155344 | 84446306 | | Tail Bearing Asm, Tapered Cone and Cup | Sold as Kit (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 6 | | 14012691 | 14012691 | 14012691 | Collapsible Spacer | Sold as Individual Part (14012691) or Kit 74010010, 74067005, 74020008 | 1 | GMT900, K2XX | 2007 - 2018 | | |
| 6 | | 40099601 | 22943114 | 40099601 | Spacer, Pinion Bearing | Sold as Individual Part (40099601) or Kit (925T1342GEARKIT, 925T1373GEARKIT) (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 7 | | 14012750 | | | Shim, Pinion | Not Offered | 1 | T1XX | 2019 - 2024 | | |
| 8 | | 40051147 | 20768576 | | Large Pinion Bearing (Cup & Cone) | NOT OFFERED | 1 | GMT900, K2XX | 2011-2018 | | |
| 8 | | 40155341 | 84446305 | | Head Bearing Asm, Tapered Cone and Cup | Sold as Kit (74067037) | 1 | T1XX | 2019 - 2024 | | |
| 9 | | 11505123 | 11505123 | | Diff. Case Bearing ASM (Cup & Cone) | NOT OFFERED | 2 | GMT900, K2XX | 2008-2018 | | |
| 9 | | 40176542 | 84678054 | | Diff Bearing Assembly | Sold as kit 74067037 | 2 | GMT900, K2XX & T1XX | 2008-2024 | | |
| 10 | | 40058282 | | | Diff Bearing Adjuster | NOT OFFERED | 2 | GMT900, K2XX | 2011-2018 | | |
| 10 | | 40163636 | 84756928 | | Diff Bearing Adjuster | Not Offered | 2 | T1XX | 2019-2024 | | |
| 11 | | 15521873 | 15521873 | 15521873 | Roller Bearing ASM (Output shaft) | Sold as Individual Part (15521873) or Kit 74010010, 74050006, 74080009 | 2 | GMT900, K2XX, T1XX | 2011-2024 | | |
| 12 | | 40058278 | 85123912 | 40058278 | Lock Ring | Sold as Individual Part (40058278) or Kit 74010010 | 2 | GMT900, K2XX, T1XX | 2011-2024 | | |
| 13 | | 40127950 | 23196678 | 40127950 | Output Seal LH (Carrier side) | Sold as Individual Part (40127950) or Kit 74010010, 74050006 | 2 | K2XX | 2014-2018 | | |
| 13 | | 40178045 | 84756924 | | Output Seal LH (Carrier side) | Sold as Individual Part | 2 | T1XX | 2019 - 2024 | | |
| 14 | | 40058310 | | | Output Shaft LH Asm | Not Offered | 1 | GMT 900 | 2011-2018 | | |
| 14 | | 40182896 | | | Output Shaft LH Asm | Not Offered | | K2XX | 2014-2018 | | |
| 14 | | 40223783 | 84927144 | 40223783 | Output Shaft Asm LH | Sold as Individual Part | 1 | T1XX | 2019-2024 | | |
| 15 | | 40058313 | 20768561 | 40058313 | Output Shaft RH | Sold as Individual Part (40058313) | 1 | GMT 900 | 2011-2014 | | |
| 15 | | 40223780 | 84927147 | 40223780 | Output Shaft Asm RH | Sold as Individual Part | 1 | T1XX | 2019-2024 | | |
| 16 | | 40040610 | 25931953 | 40040610 | Snap Ring LH/RH Output shaft | Sold as Individual Part (40040610) or Kit 74010010, 74050006 | 2 | GMT900, K2XX | 2008-2018 | | |
| 16 | | 40200979 | 11603382 | | Snap Ring LH Output shaft | Not Offered | 1 | T1XX | 2019-2024 | | |
| 17 | | 40163647 | 11603383 | | Snap Ring RH Output shaft | Not Offered | 1 | T1XX | 2019-2024 | | |
| 18 | | 40140594 | | 40140594 | Ring & Pinion Gearset (3.42 Ratio; 2 Cut) | Sold as Individual Part (40140594) | 1 | GMT 900, K2XX | 2011-2018 | | |
| 18 | | 40058536 | 20920809 | 40058536 | Ring & Pinion Gearset (3.73 Ratio; 2 Cut) | Sold as Individual Part (40058536) | 1 | GMT 900, K2XX | 2011-2018 | | |
| 18 | | 40072307 | 20920812 | 40072307 | Ring & Pinion Gearset (4.10 Ratio; 2 Cut) | Sold as Individual Part | 1 | GMT 900, K2XX | 2011-2018 | | |
| 18 | | 40024878 | | | Ring & Pinion Gearset (4.56 Ratio; 2 Cut) | NOT OFFERED | 1 | GMT 900 | 2011-2013 | | |
| 18 | | 40182620 | 84756917 | | Gear set 3.42 | Sold as Kit (925T1342GEARKIT) | 1 | T1XX | 2019 - 2024 | | |
| 18 | | 40182621 | 84756940 | | Gear set 3.73 | Sold as Kit (925T1373GEARKIT) | 1 | T1XX | 2019 - 2024 | | |
| 19 | | 40058275 | 20768562 | | Differential Open Case (Without Internals) | Not Offered | 1 | GMT 900 | 2011-2014 | | |
| 19 | | 40169952 | 84125252 | 40169952 | Differential Open Case (Without Internals) | Sold as Individual Part (40169952) | 1 | GMT 900, K2XX | 2011-2018 | | |
| 19 | | 40058274 | 20768568 | | Differential Open Case Assembly (With Internals) | Not Offered | 1 | GMT 900 | 2011-2014 | | |
| 19 | | 40169951 | 84125251 | 40169951 | Differential Open Case Assembly (With Internals) | Sold as Individual Part (40169951) | 1 | GMT 900, K2XX | 2011-2018 | | |
| 19 | | 40186599 | | 40186599 | Case Asm, Differential | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| 20 | | 26051484 | 26051484 | | Pinion gear | Sold as kit 74040363 | 2 | GMT 900 | 2007 - 2010 | | |
| 21 | | 14012699 | 14012699 | | Pinion washer | Sold as kit 74040363 | 2 | GMT 900 | 2007 - 2010 | | |
| 22 | | 40035216 | | | Side gear | Sold as kit 74040363 | 2 | GMT 900 | 2007 - 2010 | | |
| 23 | | 14012697 | 14012697 | | Side gear washer | Sold as kit 74040363 | 2 | GMT 900 | 2007 - 2010 | | |
| 24 | | 14012700 | 14012700 | | Pinion Shaft | Sold as kit 74040363 | 1 | GMT 900 | 2007 - 2010 | | |
| 25 | | 14012702 | 14012702 | | Pinion shaft lock screw | Sold as kit 74040363 | 1 | GMT 900 | 2007 - 2010 | | |
| 26 | | 14012703 | 14012703 | 14012703 | Ring Gear Bolt W/ Adhesive | Sold as Individual Part (14012703) or Kit 74010010 | 12 | GMT900, KXX | 2011-2018 | | |
| 26 | | 40064367 | 11546991 | 40064367 | Ring Gear Bolt 9.25/9.5 M12 X 1.5 | Sold as Individual Part | 12 | T1XX | 2019 - 2024 | | |
| 27 | | 40039752 | 20768584 | 40039752 | Fill Plug | Sold as Individual Part | 2 | K2XX | 2014-2018 | | |
| 27 | | 40162331 | 11602812 | 40162331 | Plug, Fill/Drain | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| 28 | | 40058296 | 20768579 | | Gasket, Coverpan | Sold as Individual Part | 1 | GMT-900, K2XX | 2011 - 2018 | | |
| 28 | | 40215582 | 85132825 | 40215582 | Gasket, Coverpan | Sold as Individual Part | 1 | GMT-900, K2XX, T1XX | 2011 - 2024 | | |
| 29 | | 40058288 | 20768577 | 40058288 | Coverpan | Sold as Individual Part | 1 | GMT900, K2XX | 2011-2018 | | |
| 29 | | 40164511 | 84756922 | | Coverpan | Sold as Individual Part | 1 | T1XX | 2021 - 2024 | | |
| 30 | | 40166465 | 11602482 | 40166465 | Cover Pan Bolt, M8 X 1.25 | Sold as Individual Part | 12 | GMT-900, K2XX, T1XX | 2019 - 2024 | | |
| 31 | | 40058285 | 20768560 | 40058285 | Intermediate Shaft Assembly | Sold as Individual Part (40058285) or Kit 74080009 | 1 | GMT 900, K2XX | 2011-2018 | | |
| 31 | | 40164318 | 84756929 | | Shaft, Intermediate (Asm) STD Axle | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| 32 | | 40007173 | 26060073 | 40007173 | Actuator, Disconnect | Sold as Individual Part | 1 | GMT-900 | 2011-2016 | | |
| 32 | | 40097241 | 22876132 | 40097241 | Actuator, Disconnect | Sold as Individual Part | 1 | K2XX | 2016-2018 | | |
| 32 | | 40190486 | 84756932 | 40190486 | Actuator, Disconnect | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| 33 | | 15588371 | 15588371 | 15588371 | SPRING - SHIFTER FORK | Sold as Individual Part | 1 | GMT-900, K2XX, T1XX | 2011 - 2024 | | |
| 34 | | 40007547 | 12479213 | 40007547 | SHIFTER FORK ASM | Sold as Individual Part | 1 | GMT-900, K2XX, T1XX | 2011 - 2024 | | |
| 35 | | 40051849 | 25931932 | 40051849 | THRUST WASHER - TUBE AND SHAFT | Sold as Individual Part | 1 | GMT-900, K2XX | 2011 - 2018 | | |
| 35 | | 40163648 | 11603380 | | THRUST WASHER - TUBE AND SHAFT | Not Offered | 1 | T1XX | 2019 - 2024 | | |
| 36 | | 40058298 | 20768559 | | Seal, Output RH (Tube) | Not Offered | 1 | K2XX | 2014-2018 | | |
| 36 | | 40178046 | 84756933 | | Seal, Output RH (Tube) | Not Offered | 1 | T1XX | 2019 - 2024 | | |
| 37 | | 40058706 | 20920811 | 40058706 | DOG RING 9.25 GMT900, K2XX | Sold as Individual Part | 1 | GMT-900, K2XX | 2011 - 2018 | | |
| 37 | | 40163652 | 84756930 | | DOG RING 9.25 T1XX | Not Offered | 1 | T1XX | 2019 - 2024 | | |
| 38 | | 40163626 | 11603303 | | BOLT - TUBE w/WASHER 9.25 K2XX/T1XX | Not Offered | 6 | T1XX | 2019 - 2024 | | |
| 39 | | 40008079 | | 40008079 | CAP - VENT CONNECTOR | Sold as Individual Part | 1 | GMT-900, K2XX, T1XX | 2011 - 2024 | | |
| 40 | | 40058297 | 20768580 | 40058297 | Tube Gasket | Sold as Individual Part | 1 | GMT-900, K2XX | 2011-2018 | | |
| 40 | | 40165381 | 84756927 | | GASKET, TUBE TO CARRIER EDGE BONDED 9.25 T1XX | Sold as Individual Part | 1 | T1XX | 2019 - 2024 | | |
| Kit | 74010010 | | | 74010010 | Master Install Kit: Pinion Seal, Pinion Nut Washer, Tube Bolt W/ Washer & | 40007712, 14012691, 14012703, 40058296, 40002169, 40058278, 26041516, 15521873, 26031703, | 1 | | 2010-2016 | | |
| Kit | 74067005 | | | 74067005 | Master Bearing Kit: Pinion Head Bearing Roller, Pinion Head Bearing Race, | 14012691, 00517900, 09783762, 09417782, 09417783, 26064029, 40007712, 40176544, 40176545, | 1 | | 1988-2013 | | |
| Kit | 74020008 | | | 74020008 | Pinion Seal Kit: Pinion Seal, Collapsible Spacer, Prevailing Torque Pinio | 40007712, 14012691, 09783762, 00517900 | 1 | | 1999-2012 | | |
| Kit | 74050006 | | | 74050006 | Output Shaft Seal Kit: Output Seal, Thrust Washer, Snap Ring, Roller Bear | 15521873, 26031703, 40051849, 40040610, 26036835, 40058297, 26041516, 40127950 | 1 | | 2011-2016 | | |
| Kit | 74030008 | | | 74030008 | Coverpan Kit: Coverpan, Rubber Over Metal Coverpan Gasket, Coverpan Bolt | 40058288, 40058296, 40002169, 40039752 | 1 | | 2011-2016 | | |
| Kit | 74080009 | | | 74080009 | Disconnect Shifter Kit: Tube Gasket, Tube Bolt W/ Washer & Adhesive, Retu | 40058706, 40051849, 15521873, 40058285, 15588371, 26031703, 40007173, 40007547, 40058297, | 1 | | 2011-2016 | | |
| Kit | 74040363 | | | 74040363 | Differential Gear Kit: Pinion Gear, Pinion Washer, Side Gear, Pinion Shaf | 40035216, 14012697, 14012699, 14012700, 14012702, 26051484 | 1 | | 2007-2010 | | |
| Kit | 925T1342GEARKIT | | | 925T1342GEARKIT | Ring and Pinion kit 9.25" 3.42 | Kit Includes Gearset 9.25" 3.42, spacer, seal, washer and nut | 1 | | 2019-2024 | | |
| Kit | 925T1373GEARKIT | | | 925T1373GEARKIT | Ring and Pinion kit 9.25" 3.73 | Kit Includes Gearset 9.25" 3.73, spacer, seal, washer and nut | 1 | | 2019-2024 | | |
| Kit | 74067037 | | | 74067037 | Master Bearing kit 9.25" Front Axle | Kit Includes pinion and diff bearings, washer, nut, spacer and seal | 1 | | 2019-2024 | | |
